Product Image

[ AIR-100 ] Air Shower Controller

  • 3 inch LCD display application
  • Front body detection sensor attached
  • Applicable for both automatic, manual

Detail Specification



AIR-100
Air Shower Controller



AIR-100 is an air shower controller dedicated to prevent contaminants entering from flowing into the clean room. This product is a compact product that is easy to install and has a simple space configuration as an integrated controller with monitor and main unit coupled.








More Compacted  AIR-100









AIR-100 can be installed anywhere in automatic door or manual door. And it is easy to install and use because it does not need any additional equipment or perforation for sensor installation by applying motion sensor to the front of monitor. In addition, input·output is made by cable type, so it is easy to attach and detach the controller.








Feature

• Air shower controller

• Integrated configuration of LCD display and Input/Output board

• Automatic door/manual door control and power failure return

• Shower method and direction setting possible

• Built-in motion sensor



Controller specification

  Item Contents Remarks
 Input power DC 12V

·

 Output voltage Relay contact output

User selectable

 Output contact capacity 250VAC, 5A

Relay output

 Input port 5 Port

Non-powered contact

 Output port 6 Port

Relay contact output

 Communication port 1 Port

RS-485 system

 Sensor port 1 Port

Motion detection sensor

 Operating environment -10~60 ℃ / 5~90%

Non condensing

 Storage temperature

-20~60 ℃

Non condensing

 Body weight

275g

·

 Guide weight

2EA ·




Sensor specificationItem



  Item Contents Remarks
 Sensor sensitivity 3300 V/W

·

 Sensor detection diagram

1.5 x 10 cmHz½/W

·

 Sensor range

5M

·

 Sensor range angle

138° ·



Cable specification
  Item Contents Remarks
 Cable length 3M/5M User selectable

 Cable weight

560g

When using 3M cable
